Microprocessors: 8086 with Support Chips and 80386 in Protected Mode
Author(s): P. K. Mukherjee
E-ISBN: Publication Year: 2014
Binding: Paper Back Dimension: 160mm x 240mm Weight: 472
About the book
MICROPROCESSORS aims to present to the readers, the evolution of Microprocessors.
In the first part the working of Intel 8086 processor along with all the support chips required to design an 8086 based system, the timing diagram of the different Bus Cycles and the Multiprogramming and Multiprocessing features of Intel 8086 have been discussed.
The second part covers Intel 80386 processor in Protected Mode, wherein the segmentation, paging and Multitasking features alongwith real to protected mode transition and vice-versa have also been discussed.
The book includes two chapters on design of an Intel 8086 processor based system along with inputs to write the Monitor program and Design of an 8 bit two stage pipelined processor and its implementation on XILINX VIRTEX-5 FPGA.
Table of Contents
Preface / Introduction / Introduction to Intel 8086 / Pin Outs and Bus cycle of Intel 8086 Microprocessor / The Latches (8282) / The Addressing Modes and Hand Coding of Instruction in 8086 / Memory and I/O Decoding Techniques / Input Output Techniques / Assembly Language Programming / Multi Programming and iRMX-86 / The Programmable Interrupt Controller PIC 8259 – A / Programmable Peripheral Interface the 8255 – A / Multiprocessing Capabilities of 8086 / Serial Communication and USART / Programmable Timer Counter (8254), Direct Memory Access Controller (8237) and Key Board and Display Controller (8279) / Memory / An 8086 Based System Design / Intel 80386 / Privilege Levels and Protection Mechanism / Paging in 80386 / Multi Tasking Capabilities of 80386 / Handling Faults and Interrupts / Real Mode Operation of 80386 / Pipelined 8 Bit Processor / References / Index.
